Ultimate Power UP12/600LP-CG 600W Pure Sine Inverter-Charger GFCI

600W CETL pure sine inverter-charger with GFCI, 4-stage charging, and selectable protections for demanding commercial use.

Description Specifications Downloads

Description

The Ultimate Power UP12/600LP-CG is a heavy-duty 600W pure sine inverter-charger engineered for demanding commercial, municipal, and utility applications. This low-profile unit delivers a continuous 600-watt output (with 750W max and 1800W surge capacity) and features a GFCI duplex outlet for increased operator safety in the field. Certified with CETL US listing, it achieves 90% peak efficiency and maintains precise voltage and frequency tolerances, ensuring reliable operation of sensitive equipment. Its pure sine wave output delivers less than 5% THD, supporting clean, consistent power for electronics, tools, and critical devices.

This inverter-charger supports a wide DC input range of 10-16V, with selectable low battery alarm and shutdown settings for dependable power management. It includes a 4-stage battery charger with automatic transfer relay and up to 25A charging for varied battery chemistries. Designed for harsh job site use, operating from -4°F to 122°F, and housed in a compact chassis for straightforward installation.

Ultimate Power serves clients nationwide with sales, service, and genuine parts for all equipment. We support the complete Ultimate Power inverter-charger lineup and provide fast solutions to maximize your equipment uptime.

Specifications

Chassis & Mounting Specifications

Dimensions with mounting holes: 14 5/16 x 7″ x 5 1/2″
Dimensions without mounting holes: 14 5/16″ x 6 1/8″ x 5 1/2″
Weight: 19 lbs

Inverter-Charger System Specifications

Model Number: UP12/600LP-CG
CETL US Listed
Continuous Output Power: 600W/5A
Maximum Output Power: 750W/6.2A
Surge Range Max: 1800W/15A
Not designed for electric motor starting (N/A)
Efficiency: 90% peak
Output Voltage (RMS): 120Vac ± 2%
Output Frequency: 60Hz ± 0.03%
Output Waveform: Pure Sine Wave, <5% THD typical
Input Voltage Regulation: 10 to 16VDC
Input Current (at 12.5Vdc): 48A
Low Battery Alarm: Selectable 12.4 or 11.5VDC
Low Battery Shutdown: Selectable 11.9 or 11VDC
Operating Temperature: -4°F to 122°F (-20°C to 50°C)
Warranty: 5 years / 2 Years Advance Replacement
Optional Remote Panels: LCD and LED

Battery Charging & Safety Features

4-Stage charger (Bulk, Accept, Float, Desulfation)
Automatic Transfer Relay: 15A, Transfer Time 10ms ± 4ms
Input Voltage Range (AC): Selectable 100–135Vac or 90–135Vac
Charger Output: Up to 25A DC, voltage dependent on battery type
Start-up Battery Voltage: 0 – 15.7VDC
Over Charge Protection: Shutdown at 16VDC

Unit Protections & Additional Features

Automatic overload / short circuit protection
Automatic high battery alarm/shutdown (16Vdc)
Automatic over-temperature alarm/shutdown
Thermally controlled cooling fan
Adjustable low battery trip voltage
AC input/output connections with GFCI
Remote 12Vdc switch connection
Auto generator start function
Case design: Low Profile
